Schneider Overload Thermal Protector (Overload) – 10A – Class 13-9 – LRD16

The Schneider LRD16 overload relay provides advanced protection for electric motors against overloads and phase failure, with a practical design compliant with international standards.

Specifications

• Brand: Schneider
• Product Type: Overload Relay
• Model Number: LRD16
• Rated Current: 9–13 A
• Class: A 10

Features

• Advanced thermal protection for three-phase motors up to 11 kW at 400 V.
• Differential device detects load imbalance and phase failure.
• Thermal adjustment dial, manual/automatic reset switch, test switch for simulation, reset/stop buttons, and signal indicator.
• Extra contacts 1NO+1NC for error signaling.
• Protective cover for the setting box with secure locking.
• Screw clamp terminal connections compatible with three-pole contactors LC1D25-D38.
• DIN rail or screw mounting using terminal block LAD7B106 (sold separately).
• Certified by IEC, UL, CSA, CCC, EAC, ATEX, Marine; Green Premium (RoHs/Reach) compliant.

Uses

• Protects motors from overload that may cause overheating and damage.
• Disconnects power when the load exceeds the set current to prevent electrical faults.
• Reduces risk of electrical hazards due to overheating and overload.
• Installed alongside contactors for comprehensive motor and operational system protection.

FAQ

Can it be used for all three-phase motors?

Yes, designed for three-phase motors up to 11 kW at 400 V.

Can the relay reset automatically?

Yes, it features a manual/automatic reset switch.

Is it compliant with international safety standards?

Yes, certified by IEC, UL, CSA, CCC, EAC, ATEX, Marine and Green Premium compliant.
